Device name: AC46TM-4000Heavy type high precision vertical Turning and Milling Center
Country: Italy
Rotary table: Φ4000
Weight: 80Ton
Cutter Storage: 60
Attachment Head Storage: 12
Max diameter: Φ4600
Maximum working height: 4000
Work piece size tolerance level IT4
Work piece shape and position
tolerances IT4 level
Work piece surface roughness up Ra0.8
Investment: $ 7.3 million
Five axis machining center
4000×4000 Vertical turning milling center
4000/100-T Processing center
KVL-1600ATC＋C-ⅡCNC machine
|
No. |
Item |
Type |
Specification (processing range) |
Precision |
Num. |
Provider |
Date of use |
|
1 |
Five axis NC machining center of Longmen milling boring machine |
XHV2420×40 |
2000×4000 |
0.01/Ra1.6 |
1 |
Ji'nan second machine tool factory |
2007.12 |
|
2 |
NC Milling Machining Center |
GMB1620 |
1600×2000 |
0.01/Ra1.6 |
2 |
Shenyang machine tool (Group) Co., Ltd. |
2006.10 |
|
3 |
8 meters CNC double column vertical lathe |
CKJQD5280/2 |
Ø 8000 |
0.025/Ra1.6 |
1 |
Wuhan Weitai CNC machinery company |
2006.11 |
|
4 |
CNC horizontal boring and milling machine |
TK6111 |
Ø 110 |
0.01/Ra1.6 |
1 |
Kunming machine tool factory |
2006.1 |
|
5 |
CNC turning milling composite center |
EM8/51P |
φ300×600 |
0.003/Ra0.8 |
1 |
USA Hardinge |
2004.9 |
|
6 |
Vertical machining center |
GX1000 |
1000×500×600 |
0.005/Ra1.6 |
1 |
USA Hardinge |
2006.1 |
|
7 |
Vertical machining center |
MV-50 |
580×580×990 |
0.01/Ra1.6 |
1 |
Shfriends machinery company |
2006.3 |
|
8 |
Vertical machining center |
MCV1580 |
500×600×1000 |
0.01/Ra1.6 |
1 |
Shfriends machinery company |
2006.5 |
|
9 |
2.5 meters CNC vertical lathe |
SVT250×16/16RIV |
Ø2500×1600 |
0.01/Ra1.6 |
1 |
Qiqihar Heavy CNC Company |
2009 |
|
10 |
CNC horizontal boring and milling machine |
TK6916 |
Ø 160 |
0.01/Ra1.6 |
1 |
Wu Heavy Machinery Co., Ltd. |
2010 |
|
11 |
1.6 meters CNC vertical lathe |
CX5116EX10/5 |
Ø 1600×1000 |
0.01/Ra1.6 |
1 |
Qiqihar Heavy CNC Company |
2010 |
|
12 |
CNC lathe |
EM8/51 |
φ300×600 |
0.003/Ra0.8 |
1 |
The United States of America |
2006.1 |
|
13 |
CNC lathe |
CAK6150P |
Ø 500×890 |
0.01/Ra1.6 |
5 |
Shenyang first machine tool factory |
02.8-06.4 |
|
14 |
CNC lathe |
CAK6763 |
Ø 630×1000 |
0.01/Ra1.6 |
2 |
Dalian machine tool factory |
2003.11 |
|
15 |
CNC lathe |
CAK6150 |
Ø 500×1500 |
0.01/Ra1.6 |
2 |
Dalian machine tool factory |
2003.11 |
|
16 |
CNC lathe |
e-CA6140 |
Ø 400×920 |
0.01/Ra1.6 |
8 |
Shenyang first machine tool factory |
2005.11 |
|
17 |
Vertical CNC lathe |
CX5112A/3 |
Ø 1200 |
0.02/Ra3.2 |
2 |
Wafangdian City machine tool factory |
1997.9 |
|
18 |
Vertical CNC lathe |
CX576B |
Ø 630 |
0.02/Ra3.2 |
2 |
Wafangdian City machine tool factory |
1997.9 |
|
19 |
Vertical CNC lathe |
CX5225 |
Ø 2500 |
0.025/Ra3.2 |
1 |
Wafangdian City machine tool factory |
1982.1 |
|
20 |
Vertical CNC lathe |
C5225E×16/10 |
Ø 2500 |
0.025/Ra3.2 |
5 |
Qiqihar Heavy CNC Company |
04.6-06.3 |
|
21 |
Vertical CNC lathe |
C5250E |
Ø 5000 |
0.025/Ra3.2 |
1 |
Qiqihar Heavy CNC Company |
2007.1 |
|
22 |
Vertical athe |
C5112A |
Ø 1250 |
0.02/Ra3.2 |
2 |
Qigihar machine tool factory |
2002.9 |
|
23 |
Vertical athe |
CA5116E×14/5 |
Ø 1600 |
0.02/Ra3.2 |
6 |
Qiqihar Heavy CNC Company |
04.3-06.3 |
|
24 |
Vertical athe |
DVT400×25/32 |
Ø 4000 |
0.02/Ra3.2 |
1 |
Qiqihar Heavy CNC Company |
2005.11 |
|
25 |
Double column vertical lathe |
C5225E×16/10 |
Ø 2500 |
0.02/Ra3.2 |
1 |
Wafangdian City machine tool factory |
2003.6 |
|
26 |
Ordinary lathe |
CW61125GP/9000 |
Ø 1250×9000 |
0.02/Ra3.2 |
1 |
Shenyang machine tool factory |
|
|
27 |
Ordinary lathe |
CW6480C |
Ø 800×1500 |
0.01/Ra3.2 |
4 |
Fuzhou machine tool factory |
1998.8 |
|
28 |
Ordinary lathe |
CW6263 |
Ø 630×1500 |
0.01/Ra3.2 |
51 |
Shenyang, Dalian machine tool factory |
98.8-06.5 |
|
29 |
Ordinary lathe |
L-5A |
Ø 500×1000 |
0.01/Ra3.2 |
25 |
Shanghai second machine tool factory |
1998.3 |
|
30 |
Ordinary lathe |
C6132A |
Ø 320×750 |
0.01/Ra3.2 |
3 |
Guangzhou machine tool factory |
1998.8 |
|
31 |
Ordinary lathe |
CA6140 |
Ø 400×750 |
0.01/Ra3.2 |
9 |
Dalian machine tool factory |
1998.5 |
|
32 |
Ordinary lathe |
CA6150B |
Ø 500×1000 |
0.01/Ra3.2 |
65 |
Dalian machine tool factory |
03.4-04.4 |
|
33 |
Ordinary lathe |
CW6193B |
Ø 930×1500 |
0.01/Ra3.2 |
3 |
Shenyang machine tool factory |
2006.2 |
|
34 |
Ordinary lathe |
CA6150 |
Ø 500×1000 |
0.01/Ra3.2 |
13 |
Shenyang machine tool factory |
2005.11 |
|
35 |
Radial drilling machine |
Z3032 |
Ø 32 |
0.1/Ra6.3 |
22 |
Nanjing fourth machine tool factory |
03.8-06.2 |
|
36 |
Radial drilling machine |
Z3050 |
Ø 50 |
0.1/Ra6.3 |
37 |
Nanjing fourth machine tool factory |
03.8-06.2 |
|
37 |
CNC boring machine |
TK6111 |
Ø 110 |
±0.008 |
1 |
Kunming machine tool factory |
2004.12 |
|
38 |
Horizontal boring machine |
TX68 |
Ø 85 |
0.01/Ra3.2 |
15 |
Kunming machine tool factory |
97.1-04.4 |
|
39 |
Horizontal boring machine |
TX619T |
Ø 90×600 |
0.01/Ra3.2 |
6 |
Kunming machine tool factory |
2004.9 |
|
40 |
Surface grinding machine |
MA7120 |
1000×330 |
300：0.005/Ra0.4 |
2 |
Shanghai machine tool factory |
2004.6 |
|
41 |
Cylindrical grinder |
MC1363/5000 |
Ø630×5000 |
0.005/Ra0.4 |
9 |
Shanghai machine tool factory |
97.8-06.2 |
|
42 |
Cylindrical grinder |
M1450×3000 |
Ø 500×3000 |
0.005/Ra0.4 |
1 |
Shanghai machine tool factory |
2006 |
|
43 |
Light Longmen milling machine |
XQ-2017 |
1700×6000 |
0.02/Ra3.2 |
1 |
Oriental machine tool factory |
2005.10 |
|
44 |
Vertical lifting milling machine |
X5032 |
1320×320 |
0.02/Ra3.2 |
18 |
Qigihar second machine tool factory |
97.10-06.1 |
|
45 |
Universal milling machine |
X6132C |
1320×320 |
0.02/Ra3.2 |
9 |
Qigihar second machine tool factory |
2006 |
|
46 |
openside planing machine |
B1012A/1 |
1.5×4 |
IT7/Ra3.2 |
1 |
Ji'nan second machine tool factory |
2004.5 |
|
47 |
Longmen light planer |
BXQ2316 |
4000×1600 |
IT7/Ra3.2 |
1 |
Taiyuan first machine tool factory |
2006.8 |
|
48 |
shaping machine |
BQ60100 |
1000×800 |
IT7/Ra3.2 |
2 |
Qingdao Machinery Factory |
2004.11 |
|
49 |
Slotting machine |
B5032 |
320 |
0.02/Ra3.2 |
4 |
Fushun machine tool factory |
97.7-06.3 |
|
50 |
Slotting machine |
BY5050E |
500 |
0.02/Ra3.2 |
1 |
Changsha machine tool factory |
2004.8 |
|
51 |
Broaching machine |
L6120 |
196kN |
0.08：200/Ra3.2 |
1 |
Changsha machine tool factory |
2001.4 |
|
52 |
Automatic band sawing machine |
HA-250 |
250mm |
0.4：100/Ra12.5 |
1 |
Shanghai Hunan saw factory |
2007 |
|
53 |
Automatic band sawing machine |
GEK-4240 |
400mm |
0.4：100/Ra12.5 |
1 |
Shanghai Hunan saw factory |
2007 |
|
54 |
Wire cutting machine tool |
DK7780J |
800×1200 |
0.03/Ra6.3 |
1 |
NC Machine Tool Co., Ltd. |
2005.2 |
|
55 |
Wire cutting machine tool |
DK7763 |
800×630 |
0.03/Ra6.3 |
1 |
NC Machine Tool Co., Ltd. |
2005.8 |
|
56 |
Wire cutting machine tool |
DK7740 |
400×500 |
0.03/Ra6.3 |
2 |
NC Machine Tool Co., Ltd. |
2006.3 |
|
57 |
6 axis 5 linkage Longmen milling boring machining center |
|
8000×3000 |
IT5/Ra0.8 |
1 |
Imported |
|
|
58 |
9 axis 5 linkage boring and milling machining center |
|
Ø200;3500×3500; X axis:12m; Y axis:4.5m; Z axis:1.35m; W axis:1.35m; V axis:2.5m; U axis:±200mm; A axis:±950;B axis:±n×3600; C axis:±n×3600 |
IT5/Ra0.8 |
1 |
Imported |
|
|
59 |
4 m x 4 m vertical turning milling center |
|
Ø4000×4000 |
IT5/Ra0.8 |
1 |
Imported |
|
|
60 |
2.5 m x 2.5 m vertical turning milling center |
|
Ø2500×2500 |
IT5/Ra0.8 |
1 |
Imported |
|
|
61 |
5 axis machining center |
STC1000 |
1000×1000 |
IT6/Ra1.6 |
1 |
Imported |
|
No. |
Item |
Type |
Specification (processing range) |
Num. |
Provider |
Date of use |
|
1 |
Silicon welding rectifier |
ZXG7-300-01 |
20~300A |
36 |
Jiangnan Electric welding machine factory |
1997.8 |
|
2 |
Electric welding machine |
SD-5002CY |
60~500A |
1 |
Japan Sanrex |
2006.5 |
|
3 |
Argon arc welding machine |
SA-300TP |
5~300A |
2 |
Japan Sanrex |
2005.1 |
|
4 |
Argon arc welding machine |
NB-500M |
0~600A |
15 |
Shanghai Dongsheng welding equipment factory |
2001.9 |
|
5 |
Argon arc welding machine |
WS—160 |
0~160A |
1 |
Shanghai electric welding machine Co., Ltd. |
2001.4 |
|
6 |
Argon arc welding machine |
QZF-1200 |
0~400A |
2 |
Shanghai electric welding machine Co., Ltd. |
2001.4 |
|
7 |
DC argon arc welding machine |
NSA4-30 |
0~30A |
3 |
Shanghai electric welding machine Co., Ltd. |
2001.9 |
|
8 |
Pulsed argon arc welding machine |
WSM-160 |
0~160A |
2 |
Shanghai electric welding machine Co., Ltd. |
2001.4 |
|
9 |
Argon arc welding machine |
ZXT-400ST |
0~500A |
2 |
Shanghai electric welding machine Co., Ltd. |
|
|
10 |
Carbon dioxide gas shielded welding machine |
NBC-500 |
0~600A |
18 |
Shanghai Dongsheng welding equipment factory |
2006.9 |
|
11 |
Telescopic arm welding machine |
XZH |
3×3/M |
1 |
Shanghai racing feather Machinery Co., Ltd. |
2007.11 |
|
12 |
Convex welder |
TN550-4 |
0~100A |
2 |
Chengdu electric welding machine |
2002.9 |
|
13 |
Spot welding machine |
DTN-50 |
0~150A |
3 |
Shanghai electric welding machine Co., Ltd. |
2003.9 |
|
14 |
Spot welding machine |
DN2—50 |
0~150A |
1 |
Shanghai Shenhua electric welder factory |
2001.7 |
|
15 |
Numerical control plasma cutting machine |
HNC-3000 |
4000×2200×100 |
1 |
Shanghai Huawei welding machinery company |
2007.9 |
|
16 |
Air plasma cutting machine |
LGK-120 |
40 |
10 |
Shanghai Dongsheng welding equipment factory |
2001.8 |
|
17 |
Automatic control far infrared welding electrode drying box |
ZYH-60 |
30mm |
1 |
Shanghai God mold welding equipment Co., Ltd. |
2004.11 |
|
18 |
Laser welding center |
JZH3000 |
350×350 |
1 |
Shanghai Leiou laser equipment company |
2005.7 |
|
No. |
Item |
Type |
Specification (processing range) |
Num. |
Provider |
|
1 |
Box type resistance furnace |
RX3-45-12 |
45KW；650℃ |
1 |
Danyang, Jiangsu |
|
2 |
Box type resistance furnace |
RX3-65-12 |
65KW；1200℃ |
1 |
|
|
3 |
Well type resistance furnace |
|
Ø1×3.5M；210KW；1200℃ |
1 |
|
|
4 |
Well type resistance furnace |
|
Ø1×2.5M；180KW ；1200℃ |
1 |
|
|
5 |
Well type resistance furnace |
|
Ø1×3.5M；120KW ；650℃ |
1 |
|
|
6 |
Car type resistance furnace |
|
3×1.5×1.2M ；300KW；1200℃ |
1 |
|
|
7 |
Self circulating double cooling groove |
|
2500×2500×5000×2；2000×2000×3000×2 |
2 |
|
|
8 |
Single column hydraulic correction machine |
|
|
1 |
|
|
9 |
Sample cutting machine |
QG-1 |
50×50mm |
1 |
|
|
10 |
Polishing machine |
PG-1A |
Ø220mm |
1 |
|
|
11 |
Sample Mosaic machine |
XQ-1 |
Ø45×55mm |
1 |
|
|
12 |
Portable digital temperature measuring instrument |
TES1310 |
|
1 |
|
No. |
Item |
Type |
Specification (processing range) |
Num. |
Provider |
Date of use |
|
1 |
punching machine |
JH23-100 |
100T |
1 |
World Precision Machine Co. Ltd. |
2006.3 |
|
2 |
punching machine |
JH23-63 |
63T |
1 |
World Precision Machine Co. Ltd. |
2006.3 |
|
3 |
punching machine |
JH23-25 |
25T |
1 |
World Precision Machine Co. Ltd. |
2006.3 |
|
4 |
punching machine |
JH21-200 |
200T |
1 |
World Precision Machine Co. Ltd. |
2007.4 |
|
5 |
2000KNSingle moving plate punching machine |
YF27-200 |
200T |
1 |
Huzhou machine tool factory |
2005.5 |
|
6 |
Roll press |
JH23-16(200) |
16T-200T |
13 |
World Precision Machine Co. Ltd. |
2005.11 |
|
7 |
Hydraulic drawing machine |
Y27-200 |
200T |
1 |
Hebei Dongfeng forging machinery |
2007.7 |
|
8 |
Hydraulic drawing machine |
Y32-500 |
500T |
1 |
Hebei metalforming equipment company |
2007.1 |
|
9 |
Bending machine |
WB11-3X1200 |
1.2m |
2 |
Tai'an Tai Chun forging machinery company |
2001.7 |
|
10 |
Hydraulic shears |
QC121-6×2500 |
6×2500mm |
1 |
Anhui Aerospace Machine Tool Manufacturing Co., Ltd. |
2005.11 |
|
No. |
Item |
Type |
Specification (processing range) |
Num. |
Provider |
Date of use |
|
1 |
Bearing heater |
ZRQ-Ⅱ |
Ø300-Ø600 |
5 |
Shanghai God mould Electric Co., Ltd. |
01.5-05.12 |
|
2 |
Pulse bag filter |
YDMC24-120Ⅱ-60 |
|
3 |
Wujin Jiangsu dust removal machinery factory |
02.3-02.1O |
|
3 |
Electric heating oven |
RD-60-2 |
|
3 |
Shanghai electric furnace |
01.7-04.11 |
|
4 |
Air compressor |
V-0.7/7 |
0.17-3m3/min |
26 |
Shanghai Changsheng compressor factory |
98.4-06.4 |
|
5 |
Shot blasting machine |
Q378E |
|
3 |
Qingdao Huaqing group |
1998.8 |
|
6 |
Vibration ageing device |
VSR-N6 |
|
2 |
Helen Huantian VSR equipment company |
2004 |
|
7 |
Laser rapid prototyping |
HRPS-IV |
480×480×380 |
1 |
Wuhan Binhu electrical and mechanical technology industry |
2007 |
